Millimeter-precise AR for pipe's positioning error

Screenshot 2024 08 21 114944

Share this

21 August 2024

Inaccuracies in mission critical construction can derail projects if left unchecked. The margin for error is razor-thin, making many issues nearly impossible to detect with the naked eye.

By deploying engineering grade augmented reality™ on this data center project, our Field Application Engineer identified a 25mm positioning error. Though seemingly minor, this discrepancy could have led to significant delays if left unchecked. Thanks to our FAE's sharp observation, the issue was promptly reported to the General Contractor, enabling early resolution before it became a larger problem.
