Precise Precast Panels with AR

Screenshot 2024 08 21 120440

Share this

21 August 2024

In mission critical construction, precision is paramount. Eyeballing and guestimating measurements is not an option - everything needs to be spot on.🎯

Our Field Application Engineer recently captured a video at one of our hyperscale data center partner's sites. The video shows a precast panel being lowered into place, lining up exactly with our hologram overlay.

By having XYZ onsite, this project team were given the confidence that every installation is exactly where it should be, creating a 'build it right, first time' culture.
